Name：Permanent magnet dc motor

Selection of DC motor type

Type	Appropriate gear box	Voltage (V)	Current (A)	Revolution (RPM)	Output (W)	Torque (KG-CM)	Rated Time (MIN)	Allowable loading capacity (KG)
TWT-06SP TWT-06SGN	3GN	12	2.4	1800	20	1.08	CONT.	1.0
		24	1.2	1800	20	1.08
		90	0.32	1800	20	1.08
TWT-06SP	一	12	4.2	3200	36	1.1	30 MIN.	1.0
		24	2.1	3200	36	1.1
		90	0.56	3200	36	1.1
TWT-07SP TWT-07SGN	4GN	12	3.5	1800	30	1.62	CONT.	1.3
		24	1.8	1800	30	1.62
		90	0.5	1800	30	1.62
TWT-07SP	一	12	7.0	3200	60	1.83	30 MIN …	1.7
		24	3.5	3200	60	1.83
		90	0.9	3200	60	1.83
TWT-08SP TWT-08SGN	5GN	12	4.4	1800	40	2.2	CONT.	1.7
		24	2.2	1800	40	2.2
		90	0.6	1800	40	2.2
TWT-08SP	一	12	8	3200	70	2.1	30 MIN	1.7
		24	4	3200	70	2.1
		90	1.1	3200	70	2.1
TWT-10SP TWT-10RP-H TWT-10SGN	一一 5GN	12	9	1800	65	3.5	CONT.	2.2 2.3 2.2
		24	4.5	1800	65	3.5
		90	1.2	1800	65	3.5
		180	0.6	1800	65	3.5
TWT-10SP-F	一	12	14	3200	120	3.66	60 MIN	2.3
		24	6.8	3200	120	3.66
		90	1.8	3200	120	3.66
		180	0.9	3200	120	3.66
TWT-10SP-B TWT-10SGN-B TWT-10SGU-B TWT-10SGU	5GN 5GU 5GU	12	9	1800	65	3.5	CONT.	2.65 2.6
		24	4.5	1800	65	3.5
		90	1.2	1800	65	3.5
		180	0.6	1800	65	3.5
TWT-10SP-FB	一	12	14	3200	120	3.66	60 MIN.	2.6 2.55
		24	6.8	3200	120	3.66
		90	1.8	3200	120	3.66
		180	0.9	3200	120	3.66
TWT-12SP TWT-12SGU	5GU	12	13	1800	100	7.0	CONT.	3.4
		24	6.5	1800	100	7.0
		90	1.7	1800	100	7.0
		180	0.85	1800	100	7.0
TWT-12SP	一	12	24	3600	200	6.4	60 MIN.	3.5
		24	12	3600	200	6.4
		90	3.2	3600	200	6.4
		180	1.6	3600	200	6.4
